LVDS Mixed Coax & Wire Cable
Suitable for high-data-rate transfer (1-20 Gbps/lane), Mechanical locking bar, 0.4/0.5 mm pitch, Horizontal/Vertical mating type micro-coaxial connector
-
High-Data-Rate Transfer, Ideal for USB4/Thunderbolt 4 (20 Gbps/lane) Applications
-
Mechanical Locking Bar Prevents Incomplete Mating and Back-out/Un-mating
-
Multiple Connector Options
Contact Pitch (mm):
0.5/0.4 pitch
Height:
1.10-3mm Max
Available Pin Count:10,12,14,
20, 30, 40, 50,60
Micro-Coaxial Cable (AWG):
Mating Direction:
Horizontal/Vertical
