BF550A + BSP5035 Heightened Heat Shrink Sealing and Cutting Machine – for sale

ProductCategory: Sealing and Cutting Shrink Series

The side sealing and cutting machine is suitable for automatic onlineshrink packaging of the product, the sealing part of the horizontal knifeadopts vertical drive, the longitudinal knife adopts the constant temperatureside sealing knife, and the automatic feeding or manual feeding mode can beselected, and the film is folded in half and can be sealed on three sides.Technical features: The longitudinal sealing is sustainable, and the length ofthe packaging product is not limited. Conventional machine packing speed up to15 m/min (medium speed machine packing speed 25 m/min). Sealing and cutting arecontrolled by a servo motor to ensure accurate positioning and good sealing andcutting lines. The sealing knife has an automatic protection function to effectivelyprevent mis-cutting of the package. Scope of application: Suitable forbiscuits, books, CDs, glass products, paper towels, cards, photo frame aluminumprofiles, wood products, and other products single packaging or combinationpackaging, suitable for mass production.

Product Characteristics

1. The film-sealing aluminum alloy blade from DuPont is Teflon coated,viscosity, and high temperature resistant. The sealing will not have cracks,coke, and fume with zero pollution.

2. Equipped with entrance photo-detector for both horizontal andvertical dimensions which is easy to switch selection. It can finish thewrapping and sealing process easily for small products.

3. Material automatically feeding, the length can be auto-adjusted bythe Sensors and timer. Equipped with induction motor to automatic reelingwasted material.

4. The hand-wheel to adjust the wrapping size when changing the productwrapped, non-necessary to change the molds and bag maker.

5. Products with different sizes can be wrapped together to achievesales promotion.

6. Equipped with internal PID readout temperature controller. Thetemperature of the sealing blade is very sensitive and accurate, andadjustable. Nothing to worry about hurting the product itself by imprecisetemperature, plus the sealing blade has an automatic protection function toavoid cutting the product itself.

7. The film cutting and sealing section is equipped with a protectiveacrylic cover and automatic alarm function. It's very safe for operators. 8.The wrapping machine implements a connection with the production flow ofunmanned operations.

9. Especially designed film up-down synchronized function to correct thefilm deviation.

10. Easy-Tear function can provide based on customer requirements.

11. Suitable for large-scale seal wrapping in the industry of software,food, drink, makeup, printing, medicine, floor, ceramics, metals, etc.
